Fits 135i, 1M, 335i and 535i N54 & N55 engined vehicles.

Factory intercoolers work well on factory 135i’s, but with added boost comes added heat load. To overcome this,
Have you noticed that you have upgraded your BMW 335i or 135i power but haven't addressed the BMW 135i intercooler cooling, we have the answer. Our race inspired BMW 135i 335i intercooler kit upgrade has been designed to handle the increase in power more efficiently. Whether you are heading out for a weekend track session or taking your twin turbocharged BMW 135i to 'The One Lap of America' race this upgrade will handle the challenge.

Welcome to the Active Autowerke RAM AIR front mounted intercooler.....by moving the intercooler closer to the front and making it taller, we were able to "catch" more air going through a larger frontal area core by way of our specially designed shroud.

The frontal area of our new core is 88% larger. Dyno testing revealed a temperature drop of close to 30 degrees Fahrenheit less in the intake manifold air temperature and close to 12 more useable rear wheel HP on our Mustang MD250 dynamometer. The ambient temperature in our shop measured 92 degrees F during the test. This thing works. Further aid performance by utilizing our BMW 135i Downpipe!

Some cutting required to ensure proper fitment.

KEY FEATURES:
-Largest intercooler core fitment for BMW 135i and 335i application
-Innovative RAM AIR shroud design that channels ALL incoming cold air
-Industry standard bar and plate core design for that rugged construction
-Delivers substantially more internal airflow than the factory BMW unit
-No heat soak measured on street application
-Delivers an increase in performance consistenly
-Cast end tanks with sturdy mounting bosses
-Full aluminum piping with proper silicone hoses and clamps for a trouble free, simple install
-Detailed CD instructions featuring mostly pictures with less text.

SPECIFICATIONS:

-Intercooler core dimensions 12.00" Tall, 18.00" Wide, 3.50" Thick
-Capable for up to 550 WHP
-Finished in BLACK for a stealth look

Intercooler core dimensions 12.00" Tall, 18.00" Wide, 3.50" Thick

NOTE: PLEASE STATE EXACT MODEL AND YEAR OF VEHICLE WHEN ORDERING.

Estimated Volumetric Shipping Weight : 10.00 Kg



Click to Enlarge

Ref: 700001019

The performance package for the BMW E60-series 535d 635d consists of the intercooler upgrade kit, the downpipe kit and fits the following vehicles.

BMW E60/61 535d E60/E61 210KW/286PS (2006-2009)
BMW E63/64 635d E63/E64 210KW/286PS (2006-2010)

Intercooler Upgrade Kit 200001060

This Performance intercooler has the following core size (530mm x 244[134]mm x 150[50]mm / stepped = 13.500 cm³), providing a 87% larger frontal area and 95% more volume compared to the original intercooler. Our engineers have increased the intercooler core size and efficiency, as well as improved the end tank design to remove any OEM bottlenecks, resulting in increased flow rating and charge cooling properties. High-performance Intercooler core with turbulators in a stepped design (weight: 9,8kg). Constructed of the highest quality Bar and Plate intercooler cores combined with cast aluminium optimised by CAD. Flow analyses and simulations were created to optimise the design for best possible Internal Airflow. This intercooler is the best choice when it comes to performance gains and low intake temperatures. A lot less pressure drop then OEM Intercooler. Anti Corrosion protective Coating with perfect thermal heat dissipating character. Optimal cooling with clearly more power. Kit is ready for installation (plug & play), using the stock plumbing. No cutting or bumper removal required. Fitment is easy, replacing the OEM intercooler.

Package:
- 1 Charge air cooler
- 1 Installation instructions

Downpipe-Kit 500001009

Original BMW Part Number: 18308508523

- Made out of SS304
- 100% perfect fit, 1:1 OEM replacement
- Less thermal load on the turbocharger
- More power by reducing back pressure
- Significantly more torque

*ECU will need to be coded to avoid engine management light errors.

Estimated Volumetric Shipping Weight : 15.00 Kg



Click to Enlarge

Click to Enlarge

Click to Enlarge

Ref: 500001009

The Wagner-Tuning Downpipe-Kit fits to:

M57 engines

- BMW 335d E90/E91/E92/E93 (2006-2011)
- BMW 535d E60/E61 (2006-2009)
- BMW 635d E63/E64 (2006-2010)
- BMW X3 E83 3.0sd (2006-2010)
- BMW X5 E70 3.0sd (2007-2010)
- BMW X6 E71 35dX (2007-2010)

Replacement for OEM BMW Part# 18308508523

- Made out of SS304
- 100% perfect fit, 1:1 OEM replacement
- Less thermal load on the turbocharger
- More power by reducing back pressure
- Significantly more torque
- 70mm

*ECU will need to be coded to avoid engine management light errors.

- Significantly more torque
- 200cpi Catalytic Converter
- Weight: 4,0kg
- Connection diameter 105mm

Estimated Volumetric Shipping Weight : 5.00 Kg



Click to Enlarge

Click to Enlarge

Click to Enlarge

Click to Enlarge

Ref: 200001060

This Performance intercooler has the following core size (530mm x 244[134]mm x 150[50]mm / stepped = 13.500 cm?), providing a 87% larger frontal area and 95% more volume compared to the original intercooler. Our engineers have increased the intercooler core size and efficiency, as well as improved the end tank design to remove any OEM bottlenecks, resulting in increased flow rating and charge cooling properties. High-performance Intercooler core with turbulators in a stepped design (weight: 9,8kg). Constructed of the highest quality Bar and Plate intercooler cores combined with cast aluminium optimised by CAD. Flow analyses and simulations were created to optimise the design for best possible Internal Airflow. This intercooler is the best choice when it comes to performance gains and low intake temperatures. A lot less pressure drop then OEM Intercooler. Anti Corrosion protective Coating with perfect thermal heat dissipating character. Optimal cooling with clearly more power. Kit is ready for installation, using the stock pluming. No bumper removal required. Fitment is easy, replacing the OEM intercooler. All of our products undergo rigorous quality control.

Package:
- 1 Charge air cooler
- 1 Installation instructions

The BMW Performance Intercooler-Kit from Wagner Tuning fits to:

- BMW 535i 2006-2009 E60/E61 225KW/306PS*
- BMW 525d 2004-2010 E60/61 130-145KW/177-197PS**
- BMW 530d 2003-2010 E60/61 160-173KW/218-235PS**
- BMW 535d 2004-2010 E60/E61 200-210KW/272-286PS
- BMW 635d 2006-2010 E63/E64 200-210KW/272-286PS

* not for vehicles with Sport automatic transmission or Automatic transmission.
**necessary adjustments to the module support.

Estimated Volumetric Shipping Weight : 15.00 Kg
